Series: Easy Vu
IP Camera HS-IPC4557HX-F8
Model: hs-ipc4557hx-f8
Resolution4MP
HousingEyeball
Lens TypeFixed
WDR120dB
Illumination10m
Power SupplyPoE
Technologies
Megacolor
AI Functions
People CountingFace RecognitionMotion Detection
Technical Specifications
Camera
| Image Sensor | 1/1.8" CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0006 lux@F1.2 (Color, 30 IRE) | 0.0003 lux@F1.2 (B/W, 30 IRE) | 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 60 m (196.85 ft) (IR) | Up to 50 m (164.04 ft) (Warm light) |
| Illuminator On/Off Control | Auto; Manual; Zoomprio |
| Illuminator Number | 4 (Multi-core (IR + warm) light) |
| Angle Adjustment | Pan: 0°–360° | Tilt: 0°–78° | Rotation: 0°–360° |
Lens
| Lens Type | Motorized vari-focal |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm–12 mm |
| Max. Aperture | F1.2 |
| Field of View | H: 114°–48°; V: 59°–27°; D: 143°–56° |
| Iris Control | Auto |
| Iris Control Type | P-Iris |
| Close Focus Distance | 0.2 m (0.67 ft) |
| DORI Distance | Detect: 87.6 m (287.40 ft) | Observe: 35.0 m (114.83 ft) | Recognize: 17.5 m (57.41 ft) | Identify: 8.8 m (28.87 ft) *Based on EN-62676-4 standard |
Intelligence
| EPTZ | Yes |
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (classification of human, vehicle, animal); loitering detection, people gathering, parking detection. Offers Perimeter Protection Large-Scale AI Models. |
| SMD | SMD 4.0 |
| AcuPick | Uses deep learning algorithms to quickly locate targets. |
| AI SSA | Yes |
| Face Detection | Face detection, snapshot optimization, face attributes extraction (6 attributes and 8 expressions). |
| People Counting | Tripwire people counting, area people counting, queue management (day/week/month/year reports). |
| Smart Search | Work together with Smart NVR to perform refined intelligent search. |
Video
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| AI Coding | AI H.265; AI H.264 |
| Streaming Capability | 4 streams |
| WDR | 130 dB |
| Noise Reduction | 3D NR |
| Image Rotation | 0°/90°/180°/270° |
| Privacy Masking | 4 mosaics or 8 color blocks |
Audio
| Built-in MIC | Yes, built-in dual Mic |
| Built-in Speaker | Yes, built-in speaker |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
Power
| Power Supply | 12 VDC (±30%); PoE+ (802.3at); ePoE |
| Power Consumption | Basic: 4.1 W | Max.: 21.6 W (IR on + WDR + Active Deterrence) |
Environment
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Protection | IP67; IK10 |
